Adapter

AWMG 7858-6.6

Ø
4 mm safety
1.500 V CAT III
1.000 V CAT IV
No items found.
Compile order information
Ihre Artikel-Nr.
836387
Your match code
AWMG 7858-6.6
/
Select product options here
Contact Piece
Color
NI = 312, AU = 513, BRAUN = 5123, GRUEN = 231, GELB = 234, SCHWARZ = 234, GRUENGELB = 845, TRANSPARENT = 165, WEISS = 563
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.

Product Description

  • magnetic adapter with safety socket for contacting of screw heads
  • socket Ø 4 mm
  • magnetic tip Ø 6.6 mm

General information

Colour
black
,
red
,
Längen
Contact parts
Ni

(
nickel-plated
)
 /
Sleeves
Isolierteile
PA 6.6 (UL94-V2)
Inhalt
Lagerung
Steckabstand

Technical Data

Terminal
safety socket
Leitung
Mounting hole
Handle sleeve for cable
For cable cross-section
For cable diameter
Transition resistance
3 mΩ (Ni)
Rated voltage
1.500 V CAT III
,
1.000 V CAT IV
,
Rated current
4 A
Thread
Operating temperature
-20 °C to +70 °C
Max. torque
fastening nut
Tightening torque
of the nut M4
Flachsteckzunge
Einsteckfenster
Druckfederkraft
RG-Typ nach MIL-C-17
Wellenwiderstand
Seiten

Further information

Matchcode: Other colours on request.

Rated voltage & rated current: At normal ambient temperatures.
