Sicherheits-Messleitung
MSFK A442
Ø
4 mm safety
No items found.
Compile order information
Your match code
MSFK A442
…
/
…
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.
Product Description
- 2 safety lamella-basket plugs, assembled on highly flexible double-insulated PVC cable 1 mm
- 1 mm² PVC double-insulated
General information
Colour
black
,
red
,
blue
,
yellow
,
green
,
Längen
150 cm
Contact parts
Au
(
gold-plated
)
/
Sleeves
PA 6.6 (UL94-V2)
Isolierteile
Inhalt
Lagerung
Steckabstand
Technical Data
Terminal
Leitung
1 mm² PVC double-insulated
Mounting hole
Handle sleeve for cable
For cable cross-section
For cable diameter
Transition resistance
22mΩ (Au)
Rated voltage
1.000 V CAT IV
,
Rated current
16 A
Thread
Operating temperature
-10 °C to +70 °C
Max. torque
fastening nut
fastening nut
Tightening torque
of the nut M4
of the nut M4
Flachsteckzunge
Einsteckfenster
Druckfederkraft
RG-Typ nach MIL-C-17
Wellenwiderstand
Seiten
Further information
Matchcode: Other contact platings, colours, lengths, wire cross-sections, terminals and alternatives in silicone on request.
Rated voltage & rated current: At normal ambient temperatures.
